CC2500
S
WRS040
C
Page
32
of
89
options.
Refer also to
the
CC2500
Errata Note
s
[1]
.
15.4.1
PKTCTRL0.CC2400_EN
=
0
If
PKTCTRL0.CC2400_EN
=0
i
t is possible to
read back the CRC status in 2 different ways:
1)
Set
PKTCTRL1.APPEND_STATUS
=1
and
read the CRC_OK flag in the MSB of the
second byte appended to the RX FIFO after
the packet data. This requires double buffering
of the packet, i.e. the ent
ire packet content of
the RX FIFO must be completely read out
before it is possible to check whether the CRC
indication is OK or not.
2) To avoid reading the
entire
RX FIFO,
another solution is to use the
PKTCTRL1.CRC_AUTOFLUSH
feature. If this
feature is
enabled, the entire RX FIFO will be
flushed if the CRC check fails. If
GDOx_CFG
=0x06
the
GDOx
pin will be asserted
when a sync word is found. The
GDOx
pin will
be de
-
asserted at the end of the packet. When
the latter occurs the MCU should read the
number o
f
bytes in the RX FIFO from the
RXBYTES.NUM_RXBYTES
status register
.
If
RXBYTES.NUM_RXBYTES
=0 the CRC check
failed and the FIFO
is
flushed. If
RXBYTES.NUM_RXBYTES
>0 the CRC check
was OK and data can be read out of the FIFO.
15.4.2
PK
TCTRL0.CC2400_EN
=
1
If
PKTCTRL0.CC2400_EN
=
1
the CRC can be
checked as
outlined in
1) in
Section
15.4.1
as
well as
by reading the CRC_OK flag
available
in the
PKTSTATUS
[
7]
register, in the
LQI[7]
status register
or from one of the
GDO
pins if
GDOx_CFG
is 0x07 or 0x15
.
The
PKTCTRL1.CRC_AUTOFLUSH
o
r data
whitening
cannot be used when
PKTCTRL0.CC2400_EN
=
1
.
15.5
Packet Handling in Transmit Mode
The payload that is to be transmitted must be
written into the TX FIFO. The
first byte written
must be the length byte when variable packet
length is enabled. The length byte has a value
equal to the payload of the packet (including
the optional address byte).
If address
recognition is enabled on the receiver, the
second byte writ
ten to the TX FIFO must be
the address byte. If fixed packet length is
enabled, then the first byte written to the TX
FIFO should be the address (if the receiver
uses address recognition).
The modulator will first send the programmed
number of preamble byt
es. If data is available
in the TX FIFO, the modulator will send the
two
-
byte (optionally 4
-
byte) sync word and
then the payload in the TX FIFO. If CRC is
enabled, the checksum is calculated over all
the data pulled from the TX FIFO and the
result is sent
as two extra bytes following the
payload data. If the TX FIFO runs empty
before the complete packet has been
transmitted, the radio will enter
TXFIFO_UNDERFLOW state. The only way to
exit this state is by issuing an
SFTX
strobe.
Writing to the TX FIFO afte
r it has underflowed
will not restart TX mode.
If whitening is enabled, everything following
the sync words will be whitened. This is done
before the optional FEC/Interleaver stage.
Whitening is enabled by setting
PKTCTRL0.WHIT
E_DATA
=1.
If FEC/Interleaving is enabled, everything
following the sync words will be scrambled by
the interleaver and FEC encoded before being
modulated. FEC is enabled by setting
MDMCFG1.FEC_EN
=1.
15.6
Packet Handling in Receive
Mode
In receive mode, the demodulator and packet
handler will search for a valid preamble and
the sync word. When found, the demodulator
has obtained both bit and byte synchronism
and will receive the first payload byte.
If FEC/Interleaving is enabled, t
he FEC
decoder will start to decode the first payload
byte. The interleaver will de
-
scramble the bits
before any other processing is done to the
data.
If whitening is enabled, the data will be de
-
whitened at this stage.
When variable packet length
mode
is
enabled,
the first byte is the length byte. The packet
handler stores this value as the packet length
and receives the number of bytes indicated by
the length byte. If fixed packet length
mode
is
used, the packet handler will accept the
programmed number
of bytes.
Next, the packet handler optionally checks the
address and only continues the reception if the
address matches. If automatic CRC check is
enabled, the packet handler computes CRC
and matches it with the appended CRC
checksum.
At the end of the p
ayload, the packet handler
will optionally write two extra packet status
