MSP430F5529 , MSP430F5528 , MSP430F5527 , MSP430F5526
MSP430F5525 , MSP430F5524 , MSP430F5522 , MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015 www.ti.com
Table 6-58. Port PU.0/DP, PU.1/DM Output Functions
(1)
CONTROL BITS PIN NAME
PUSEL PUOPE PUOUT1 PUOUT0 PU.1/DM PU.0/DP
0 0 X X Output disabled Output disabled
0 1 0 0 Output low Output low
0 1 0 1 Output low Output high
0 1 1 0 Output high Output low
0 1 1 1 Output high Output high
1 X X X DM
(2)
DP
(2)
(1) PU.1/DM and PU.0/DP inputs and outputs are supplied from VUSB. VUSB can be generated by the
device using the integrated 3.3-V LDO when enabled. VUSB can also be supplied externally when the
3.3-V LDO is not being used and is disabled.
(2) Output state set by the USB module.
Table 6-59. Port PU.0/DP, PU.1/DM Input Functions
(1)
CONTROL BITS PIN NAME
PUSEL PUIPE PU.1/DM PU.0/DP
0 0 Input disabled Input disabled
0 1 Input enabled Input enabled
1 X DM input DP input
(1) PU.1/DM and PU.0/DP inputs and outputs are supplied from VUSB. VUSB can be generated by the
device using the integrated 3.3-V LDO when enabled. VUSB can also be supplied externally when the
3.3-V LDO is not being used and is disabled.
Table 6-60. Port PUR Input Functions
CONTROL BITS
FUNCTION
PUSEL PUREN
Input disabled
0 0
Pullup disabled
Input disabled
0 1
Pullup enabled
Input enabled
1 0
Pullup disabled
Input enabled
1 1
Pullup enabled
