16
N2200PLUS:
The N2200PLUS rear panel features ports and connectors.
Back Panel
Item
Description
System Fan
 System fan that exhausts heat from the unit
WAN Port
 WAN port for connecting to an Ethernet network through a switch
or router
LAN Port
 LAN port for connecting to an Ethernet network through a switch
or router
Reset Button
 Resets the N2200PLUS
 Immediately press the Reset button on the back. This will reset
your network setting, password.
USB Port
 USB 2.0 port for compatible USB devices, such as digital cameras,
USB disks, and USB printers.
DC IN
 For connect the power adaptor
System Fan
WAN Port
USB Port
Reset Button
DC IN
LAN Port
