b. Slide the HDD tray back into the N2200/N2200PLUS until it snaps into
place.
3. For 2.5‖ HDDs
c. Remove an HDD tray and install a 2.5‖ SATA hard disk onto it.
d. Slide the HDD tray back into the N2200/PLUS/EVO until it snaps into
place.
Cable Connections
N0204:
To connect the N0204 miniNAS to your network, follow the steps below:
1. Connect an Ethernet cable from your network to the LAN port on the back
panel of the N0204 miniNAS.
2. Connect the provided power adaptor into
the power socket on the back panel. Plug
the other end of the cord into a surge
protector socket.
3. Press the Power button on the Rear end
to boot up or shut down the N0204 miniNAS.
1. USB copy LED will be flashed Blue
light during the system are
booting and will be dull after the
booting complete.
2. To shut down the system, press
the power button over 4 seconds,
then USB copy LED will be flashed
Red light, release power button.
