Thecus N4100PRO User Manual

Front Panel
The N4100PRO’s front panel displays the unit’s array of status LED’s and is also
where you’ll find the power buttons. See the table below for a detailed explanation
of each:
Item Description
HDD Trays • There are four hard disk drive (HDD) trays. Each tray supports
a 3.5-inch SATA HDD. The trays have locks for added physical
security and keys are provided with the package.
Power LED • Solid blue: N4100PRO is powered on
Busy LED • Blinking orange: system startup or maintenance; data
inaccessible
• Off: system startup complete; system operating normally
WAN LED • Solid green: network link
• Blinking green: network activity
LAN LED • Solid green: network link
• Blinking green: network activity
Error LED • Solid red: system error detected
Power Button • Power on/off N4100PRO
Hard Disk Tray
The N4100PRO’s hard disk
trays each have a lock, a latch,
and two indicators.
11

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
