Thecus N4100PRO User Manual

Item Description
Lock • The tray lock lets you physically secure the HDD with
accessory keys.
Latch • Use the latch to open and remove or close and secure the tray.
HDD Power LED • Solid blue: HDD is powered on
Access/Error LED • Blinking yellow: data is being accessed
• Blinking red: hard disk error
Rear Panel
The rear panel of the N4100PRO houses the USB and Ethernet connections, as well
as the power connector. See the table below for descriptions of each:
Item Description
Power Connector • Connect the included power cord to this connector
WAN Port • WAN port for connecting to an Ethernet network through a switch
or router
LAN Port • LAN port for connecting to an Ethernet network through a switch or
router
USB Ports • USB 2.0 ports for storage expansion
12

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
