Thecus N4100PRO User Manual

Temperature.
Green: Systematic temperature is normal.
Red: Systematic temperature is unusual.
Click to go to System Status page as short cut.
Network.
Green: Connection to network is normal.
Red: abnormal connection to the network
Logout
Click to logout Web Administration Interface.
Language Selection
The N4100PRO supports multiple languages, including:
• English
• Japanese
• Traditional Chinese
• Simplified Chinese
• French
• German
• Italian
• Korean
• Spanish
• Russia
• Polish
On the menu bar, click Language and the selection list
appears. This user interface will switch to selected
language for the N4100PRO.
System Information
Information provides viewing on current Product info, System Status, Service
Status and Logs.
The menu bar allows you to see various aspects of the N4100PRO. From here, you
can discover the status of the N4100PRO, and also other details.
Product Information
Once you login, you will first see the basic Product Information screen providing
Manufacturer, Product No., Firmware Version, and System Up Time
information.
23

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
