LAN Configuration
Item Description
MAC Address Displays the MAC address of the LAN interface.
Jumbo Frame Support Enable or disable Jumbo Frame Support on the LAN interface.
IP Specifies the IP address of the LAN interface.
Netmask Specifies the Network Mask of the LAN interface.
Before enabling Jumbo Frame Support, please make sure your network equipment
supports Jumbo Frame. If your equipment is incompatible, you might not be able to
connect to your N4100PRO.
NOTE
DHCP Server Configuration
A DHCP server can be configured to assign IP addresses to devices connected to the
LAN port. To configure these ports, choose LAN from the System Network menu.
DHCP Configuration
Item Description
DHCP Server Enable or disable the DHCP server to automatically assign IP
address to PCs connected to the LAN interface.
Start IP Specifies the starting IP address of the DHCP range.
End IP Specifies the ending IP address of the DHCP range.
DNS Server Displayed the DNS server IP address.
NOTE
The IP Segment of WAN and LAN should not overlap.
WARNING
The IP address of the LAN interface should not be in the range of the Start
IP address and End IP address.
Samba / CIFS
There are 4 options is currently allow Admin to Enable/Disable to operate N4100PRO
associated with Samba / CIFS protocol. With the option changed, it will need to
reboot system to activate.
36
