Thecus N4100PRO User Manual

Cable Connections
Make the following connections on the Thecus N4100PRO and then power up the
unit:
1. Connect an Ethernet cable from your network to the WAN port on the back
panel of the N4100PRO.
2. Connect the provided power cord into the universal power socket on the
back panel. Plug the other end of the cord into a surge protected socket.
3. Press the power button on the front panel to power on the N4100PRO.
Checking System Status
After making connections on the N4100PRO and powering up, check whether the
system status is normal or has trouble by observing indicators on the front panel
and hard disk trays.
System Status Normal
The system status is normal if:
1. The front panel Power LED glows blue and the WAN LED glows or blinks
green.
2. The HDD Power LED on each HDD tray glows blue.
System Trouble
The system has trouble if:
1. Any LED glows red.
1. The system emits a continuous beeping sound.
If the system has trouble, please refer to Chapter 8: Troubleshooting.
WARNING
There are no user serviceable parts inside the N4100PRO. Please contact
14

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
