Thecus N4100PRO User Manual

This screenshot lists iSCSI target volumes created under thin-provisioning. The 2
nd
iSCSI target volume under thin-provisioning has been created with a capacity of
14300GB.
This message appears if there is no more room for new iSCSI target creation.
iSCSI LUN ID
NOTE
1. Each RAID volume can only create one iSCSI thin-provision volume.
2. Each thin-provision volume can only create 5 iSCSI target volumes.
3. The notification will send out while the physical size of iSCSI
thin-provision capacity has used up to 90%.
When iSCSI target volume has been created, there is a default LUN ID of 0 in
previous firmware versions which was un-configurable. From v3.00.04, it is
configurable from 1 to 254 with a default of the next available number in ascending
numerical order. The LUN ID is unique and can not be duplicated except for LUN ID
0.
115

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
