The following table illustrates the keys on the front control panel:
LCD Controls
Icon Function Description
▲ Up Button Select the previous configuration settings information.
▼ Down Button Select the next configuration settings information
↵ Enter Enter for the USB copy confirmation message.
ESC Escape Escape and return to the previous menu.
There are two modes of operation for the LCD: Display Mode and Management
Mode.
Display Mode
During normal operation, the LCD will be in Display Mode.
Display Mode
Item Description
Host Name Current host name of the system.
WAN Current WAN IP setting.
LAN Current LAN IP setting.
Link Aggregation Current Link Aggregation status
Disk Info Current status of disk slot has been installed
RAID Current RAID status.
System Fan Current system fan status.
2006/06/16 12:00 Current system time.
The N4100PRO will rotate these messages every one-two seconds on the LCD
display.
USB Copy
The USB Copy function enables you to copy files stored on USB devices such as USB
disks and digital cameras to the N4100PRO with a press of a button. To use USB
copy, follow the steps below:
1. Plug your USB device into an available USB port on the Front Panel.
2. In Display Mode, press the Enter (
↵).
3. The LCD will display “USB Copy?”
4. Press Enter (
↵) and the N4100PRO will start copying USB disks connected to
the front USB port.
5. All of data will be copied into system folder named “USBcopy”.
Typical Setup Procedure
From the Web Administration Interface, you can begin to setup your N4100PRO for
use on your network. Setting up the N4100PRO typically follows the five steps
outlined below.
For more on how to use the Web Administration Interface, see Chapter 4: System
Management > Web Administration Interface.
18
