Thecus N4100PRO User Manual

Chapter 3: First Time Setup
Overview
Once the hardware is installed, physically connected to your network, and powered
on, you can configure the N4100PRO so that it is accessible to your network users.
There are two ways to set up your N4100PRO: using the Thecus Setup Wizard or
the LCD display. Follow the steps below for initial software setup.
Thecus Setup Wizard
The handy Thecus Setup Wizard makes configuring N4100PRO a snap. To configure
the N4100PRO using the Setup Wizard, perform the following steps:
1. Insert the installation CD into your CD-ROM drive (the host PC must be
connected to the network).
2. The Setup Wizard should launch automatically. If not, please browse your
CD-ROM drive and double click on Setup.exe.
NOTE
For MAC OS X users, double click on Thecus Setup Wizard 1.2.0.dmg
3. The Setup Wizard will start and automatically detect all Thecus storage
devices on your network. If none are found, please check your connection
and refer to Chapter 8: Troubleshooting for assistance.
15

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
