Thecus N4100PRO User Manual

2. On the Local User Setting screen, enter a name in the User Name box.
3. Enter a User ID number. If left blank, the system will automatically assign
one.
4. Enter a password in the Password box and re-enter the password in the
Confirm box.
5. Select which group the user will belong to. Group Members is a list of
groups this user belongs to. Group List is a list of groups this user does not
belong to. Use the << or >> buttons to have this user join or leave a group.
6. Press the Apply button and the user is created.
NOTE
All users are automatically assigned to the ‘users’ group.
Edit Users
1. Select an existing user from the Local User Configuration screen.
2. Click on the Edit button, and Local User Setting screen appears.
3. From here, you can enter a new password and re-enter to confirm, or use the
<< or >> buttons to have this user join or leave a group. Click the Apply
button to save your changes.
75

Thecus N4100PRO Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Supported file systems	EXT3, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	4
Flash memory	128 MB
Internal memory	0.25 GB
Processor model	LX 800
Processor frequency	0.5 GHz
Wi-Fi	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS, AFP
Compliance industry standards	IEEE 802.11b, IEEE 802.11g
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	165 x 192 x 226 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Display type	LCD
Power supply unit (PSU) capacity	200 W

Weight and Dimensions

Weight	5000 g
