38
Chapter 3: System Administration
Remove RAID destroys all data in the selected RAID volume. The data
will be unrecoverable.
Expanding a RAID
To expand a RAID 1, RAID 5, or RAID 6 volume, follow the steps below:
Replace one of the hard drives in the RAID volume and allow it to automatically rebuild.1.
Once rebuilt, you can continue to replace any remaining disks in the RAID array. 2.
When you are done replacing hard drives, log on to Web Management. Navigate to Storage> 3.
RAID to open the RAID Configuration screen.
On the RAID Information screen, click Edit to open the RAID Configuration screen.4.
On the RAID Configuration screen, click Expand.5.
