THERMACUT EX-TRAFIRE 125HD - Product Identification; Marking; Identification plate; Signs and symbols used

EX-TRAFIRE
®
125HD 1 Identification
EN - 5
1 Identification
The EX-TRAFIRE
®
125HD is a portable plasma arc cutting power supply for
mechanized and manual plasma cutting, gouging, and marking. The
EX-TRAFIRE
®
125HD uses compressed air or nitrogen to cut almost all
conductive metals. The EX-TRAFIRE
®
125HD may be operated only with
original Thermacut
®
parts. This documentation describes the
EX-TRAFIRE
®
125HD cutting power supply only.
When used in this documentation, the term “device” always refers to the
EX-TRAFIRE
®
125HD cutting power supply.
1.1 Marking
This product fulfills the requirements that apply to the market to which it
has been introduced. Corresponding marking has been affixed to the
product, if required.
1.2 Identification plate
The EX-TRAFIRE
®
125HD is labeled by means of an identification plate on
the housing located under the machine.
 For inquiries, please have at hand the type and number of the
EX-TRAFIRE
®
125HD per the identification plate.
1.3 Signs and symbols used
The following signs and symbols are used:
Fig. 1 EX-TRAFIRE
®
125HD identification plate
General instructions.
Action(s) to be carried out in succession.
Lists.
Cross-reference symbol refers to detailed, supplementary or further
information.
Caption, item description.

1
A
