THERMACUT EX-TRAFIRE 125HD - 85 A cutting, shielded, with compressed air (Detailed)

EX-TRAFIRE
®
125HD 20 Cutting tables for mechanical cutting
EN - 55
20.3.1 85 A cutting, shielded, with compressed air
EX-6-421-021
EX-6-415-022
EX-6-415-021
EX-6-409-021 EX-6-401-021 EX-6-404-021
Material
thickness
Torch
(shield) to
workpiece
distance
Pierce
height
(shield) to
workpiece
distance
Pierce
delay
time
Recommended speed Maximum speed Kerf
width
Settings for
highest quality
Standard quality
settings
Cutting speed Voltage Cutting speed Voltage
[mm] [mm] [mm] [Seconds] [mm/min] [Volts] [mm/min] [Volts] [mm]
Mild steel
3
4.6
7.2
0.1 6800 134 9200 136 1.6
4 0.2 5650 138 6570 141 1.6
6
0.5
3600 143 4400 146 1.9
8 2500 145 3100 148 2
10 1680 150 1810 153 2.1
12 1280 152 1460 153 2
16 1 870 154 840 155 2.4
20
Edge start
570 161 680 163 2.5
25 350 165 405 164 2.7
30 200 173 240 169 3
Stainless steel
3
4.6
7.2
0.1 7500 146 7900 149 1.4
4 0.2 6100 146 7500 150 1.5
6
0.5
3700 148 3700 152 1.7
8 2450 151 2450 153 1.9
10 1550 151 1900 153 2.1
12 0.7 1100 158 1250 162 2.2
16
1
700 153 760 155 2.3
20
Edge start
480 158 550 160 2.4
25 300 165 350 168 2.5
Aluminum
3
4.6
7.2
0.1 8000 144 7900 146 1.9
4 0.2 6500 145 7500 148 1.9
6
0.5
3800 148 4900 150 1.9
8 2650 148 4050 150 2
10 1920 150 3000 152 2
12 0.7 1450 154 2300 157 2.1
16 1 950 156 1440 160 2.1
20
Edge start
600 160 1050 165 2.1
25 380 161 640 166 2.1
