THERMACUT EX-TRAFIRE 125HD - 125 A cutting, shielded, with compressed air (Detailed)

EX-TRAFIRE
®
125HD 20 Cutting tables for mechanical cutting
EN - 59
20.5.1 125 A cutting, shielded, with compressed air
EX-6-421-021
EX-6-415-022
EX-6-415-021
EX-6-409-021 EX-6-404-021EX-6-401-021
Material
thickness
Torch
(shield) to
workpiece
distance
Pierce height
(shield) to
workpiece
distance
Pierce
delay
time
Recommended speed Maximum speed Kerf
width
Settings for
highest quality
Standard quality
settings
Cutting speed Voltage Cutting speed Voltage
[mm] [mm] [mm] [Seconds] [mm/min] [Volts] [mm/min] [Volts] [mm]
Mild steel
6
4.6
7.2
0.2 4980 141 6555 141 2.2
8 0.3 3800 143 4570 143 2.3
10 0.4 2750 154 3330 154 2.4
12 4 0.5 1230 157 2760 157 2.4
16
4.6
0.6 1010 154 1660 154 2.6
20 0.9 980 154 1140 154 2.8
25 1 590 154 935 154 3.1
30
Edge start 1
460 156 580 156 3.6
32 400 157 500 157 3.8
35 340 160 430 160 3.9
40 240 162 310 162 4.1
Stainless steel
6
4.6
7.2
0.5
5910 143 9200 146 1.9
8 4060 148 6100 150 2.2
10 2540 152 3700 154 2.4
12 2170 152 3300 154 2.6
16 0.7 1140 155 1600 156 2.6
20 1.2 940 156 1130 158 2.7
25
Edge start
1
540 160 800 161 3.1
30 430 163 640 167 3
32 1.1 400 166 600 168 3
35
1.2
320 170 540 172 3.2
40 180 175 210 177 3.6
Aluminum
6
4.6
7.2
0.2 7660 153 8560 155 2.3
8 0.3 5100 153 3100 155 2.5
10 0.4 2980 155 4400 157 2.6
12 0.5 2140 157 3620 158 2.6
16 0.6 1540 157 2500 158 2.8
20
1.5
1260 158 1950 162 2.9
25 850 162 1250 166 2.8
30
Edge start
1 540 166 1075 170 2.9
32 1.1 430 170 750 172 3
35
1.2
370 172 580 174 3.3
40 270 174 300 176 3.7
