Thermal Arc 500 - 8.06 Front Panel Parts (Power-Master 500 P and 350 P)

POWERMASTER 500, 500P, 350, 350P
8-6
March 17, 2006
8.06 Front Panel Parts (Power-Master 500P and 350P)
ItemItem
ItemItem
Item
QtyQty
QtyQty
Qty
..
..
.
DescriptionDescription
DescriptionDescription
Description
Part NumberPart Number
Part NumberPart Number
Part Number
1 1 Overlay,Weld Schedule,PM500P 831114PKD
2 10 Spacer,.14IDx.5 Nylon, PM, IPS 204600-001
3 1 PCB, Pulse, PM500P, IPS 830831
4 4 Circuit, Breaker, 10A, 2 Pole 830362
5 2 Bushing, Insulator, PM, IPS 357654
6 2 Cover, Terminal 357655
7 2 Pin, Roll 1/8" x 2", PM, IPS 831125PKD
8 2 Bus Stud Cable, PM, IPS 5CW974
9 4 Washer,Insulation,Flat,PM,IPS 5CW976A
10 2 Washer,13mm,Flat,STZP See Note 1
11 4 Washer,13mm,Spring See Note 1
12 2 Screw,Hex HD,1/2"-13x1.75" 351505
13 2 Capacitor, 47nF 630V, PM, IPS 707158PKD
14 2 Washer,3.5mm,Spring See Note 1
15 2 Screw,PHCR,#6-32x3/8" See Note 1
16 2 Nut, Hex, 1/2"-13 400614-001
17 2 Washer,13mm,Flat,STZP See Note 1
18 2 Screw,Hex HD,M12-1.75x30,STZP See Note 1
19 1 PCB, Display, PM, IPS 830838
20 1 Door Control Assy, PM, IPS 830903WBLKPKD
21 3 Screw,PHCR,M4x12mm,Blinding See Note 1
22 1 Harness, Control Pot, PM, IPS 830935
23 2 Knob,Control,1/4" IDx1.6" 870696PKD
24 1 Cable,Ribbon,10P,6", PM, IPS 171370-005
25 1 Cable, D-SUN Assy, PM, IPS 830936
30 2 Rivet,1/8,BLIND STEEL See Note 1
31 1 Latch,Self Adjusting, PM, IPS 830960
32 3 Washer,4.4mm,Int Lock See Note 1
33 3 Nut, Hex M4X0.7, STZP See Note 1
35 1 Nut, 3/8"-32, Lock, PM,IPS 402663
36 1 Reducer, Shaft Hole 404454
37 11 Washer,3.5mm,Ext Lock See Note 1
38 11 Nut, Hex M3X0.5, STZP See Note 1
39 1 Overlay,Pulse Control,PM500P 831103PKD
Note 1:
This part is available at most hardware stores.
