Thermal Arc 500 - APPENDIX 1: GENERAL INFORMATION

POWERMASTER 500, 500P, 350, 350P
March 17, 2006
A-1
APPENDIX 1: GENERAL INFORMATION
• Note the model and specification number shown on the equipment nameplate.
• Locate these numbers in the model and specification number columns below.
• Use only those diagrams and instructions that are applicable.
SPECIFICATION NUMBER MODEL SCHEMATIC AND CONNECTION DIAGRAM
100085 POWER-MASTER 500 830921
830920
100086 POWER-MASTER 500P 830924
830925
100078 POWER-MASTER 350 830921
830920
100079 POWER-MASTER 350P 830924
830925
