Manual 0-2725 2-1 INTRODUCTION
2.03 Service Responsibilities
The Service Technician should be familiar with the equip-
ment and its capabilities. He should be prepared to rec-
ommend arrangements of components which will pro-
vide the most efficient layout, utilizing the equipment to
its best possible advantage.
Maintenance work should be accomplished in a timely
manner. If problems are encountered, or the equipment
does not function as specified, contact the Technical Ser-
vices Department for assistance.
SECTION 2:
INTRODUCTION
2.01 Scope Of Manual
This Manual provides Service Instructions for Thermal
Dynamics CutMaster 80XL (CE) Plasma Power Supply.
Refer to Operating Manual (0-2724) for individual oper-
ating procedures. Information in this manual covers the
Troubleshooting and Repair of the equipment, and is in-
tended for use by properly-trained Service Technicians
familiar with this equipment.
Read this Manual and the Operating Manual thoroughly.
A complete understanding of the capabilities and func-
tions of the equipment will assure obtaining the perfor-
mance for which it was designed.
2.02 General Service Philosophy
Several key points are essential to properly support the
application and operation of this equipment.
A. Application
The equipment should satisfy the customer’s require-
ments as supplied and as described in Section 3 of this
manual. Be sure to confirm that the equipment is capable
of the application desired.
B. Modifications
No physical or electrical modifications other than selec-
tion of standard options and Accessories are to be made
to this equipment.
C. Customer/Operator Responsibilities
It is the customer/operators’ responsibility to maintain
the equipment and peripheral Accessories provided by
Thermal Dynamics in good operating order in accordance
with the procedures outlined in the Operating Manual,
and to protect the equipment from accidental or mali-
cious damage.
D. Repair Restrictions
The electronics consists of Printed Circuit Board Assem-
blies which must be carefully handled, and must be re-
placed as units. No replacement of printed circuit sol-
der-mounted components is allowed except as noted in
this manual.
Printed Circuit Board Assemblies to be returned must be
properly packaged in protective material and returned
intact per normal procedures.
