Manual 0-2725 4-1 SERVICE TROUBLESHOOTING
SECTION 4:
SERVICE
TROUBLESHOOTING
DIAGNOSTICS
4.01 Introduction
This Section provides service diagnostics for the CutMas-
ter 80XL Power Supply, allowing the Technician to iso-
late any faulty Subassemblies. Section 5, Repairs & Re-
placement Procedures, provides parts replacement
instructions.
Under no circumstances are field repairs to be attempted
on Printed Circuit Boards or other Subassemblies of this
unit. Evidence of unauthorized repairs will void the fac-
tory warranty.
NOTE
The troubleshooting contained in this manual is
for the Power Supply only. Troubleshooting other
parts of the system is covered in the separate manu-
als for that product.
4.02 Maintenance Schedule
Refer to Appendix 12, Maintenenance Schedule, for main-
tenance procedures.
4.03 Common Operating Problems
WARNINGS
Disconnect primary power at the source before dis-
assembling the power supply, torch, or torch leads.
Frequently review the Important Safety Precau-
tions (Section 1). Be sure the operator is equipped
with proper gloves, clothing, eye and ear protec-
tion. Make sure no part of the operator’s body comes
into contact with the workpiece while the torch is
activated.
Sparks from the cutting process can cause damage
to coated, painted, and other surfaces such as glass,
plastic and metal.
Handle torch leads carefully and protect them from
damage.
A. Piloting
Piloting is harder on parts life than actual cutting be-
cause the pilot arc is directed from the electrode to
the tip rather than to a workpiece. Whenever pos-
sible, avoid excessive pilot arc time to improve parts
life.
B. Torch Standoff
Improper standoff (the distance between the torch
tip and workpiece) can adversely affect tip life as well
as shield cup life. Standoff may also significantly af-
fect the bevel angle. Reducing standoff generally re-
sults in a more square cut.
C. Edge Starting
For edge starts, hold the torch perpendicular to the
workpiece with the front of the torch tip at the edge
of the workpiece, not touching, at the point where
the cut is to start. When starting at the edge of the
plate, do not pause at the edge and force the arc to
“reach” for the edge of the metal. Establish the cut-
ting arc as quickly as possible.
D. Direction of Cut
The plasma gas stream swirls as it leaves the torch.
The purpose of the swirl is to maintain a smooth col-
umn of gas. The swirl effect results in one side of a
cut being more square than the other. Viewed along
the direction of travel, the right side of the cut is more
square than the left.
E. Dross
When dross is present on carbon steel, it is commonly
referred to as either “high speed, slow speed, or top
dross”. Dross present on top of the plate is normally
caused by too great a torch to plate distance. "Top
dross" is normally very easy to remove and can often
be wiped off with a welding glove. "Slow speed
dross" is normally present on the bottom edge of the
plate. It can vary from a light to heavy bead, but
does not adhere tightly to the cut edge, and can be
easily scraped off. "High speed dross" usually forms
a narrow bead along the bottom of the cut edge and
is very difficult to remove. When cutting a trouble-
some steel, it is sometimes useful to reduce the cut-
ting speed to produce "slow speed dross". Any re-
sultant cleanup can be accomplished by scraping, not
grinding.
