PARTS LISTS 6-6 Manual 0-2725
6.05 Left Side Internal Component Replacement Parts List
Item # Qty Description Catalog #
1 1 Insulator, Input PCB See Note
2 2 Cable Assembly, 10 Cir Ribbon, 15" Lg 9-5922
3 1 Cable, 20 Circuit Ribbon 9-7510
4 1 Logic Control PCB Assembly 9-7631
5 1 Assembly, Gate Drive PCB 9-7562
6 2 Assembly, FET Heatsink Includes: 9-7633
Assembly, FET Heatsink
7 Dust Cover, FET Assembly
8 1 Fuse Block 9-5562
9 1 Fuse, 0.8A, 600V, 13/32" Dia 9-7526
10 1 Bushing See Note
11 1 Label, Voltage Selection See Note
12 4 Standoff, #10-32 X 3/8 Hex X 2" Lg, Al See Note
13 1 Diode Bridge Assembly; Includes: 9-7542
1 Diode Bridge, 3 Phase w/Scr, 40A, 1600V
14 Thermal Pad, QIII, Input Module
15 1 Assembly, Input PCB 9-7558
16 1 Bracket, Heatsink Mounting See Note
17 1 Cable, 2 Circuit See Note
18 1 Input EMC Filter Assembly 9-7667
NOTE: Item shown for assembly purposes only.
