PARTS LISTS 6-4 Manual 0-2725
6.04 Front Panel Replacement Parts List
Item # Qty Description Catalog #
1 1 Base Front, CutMaster Includes: 9-7867
Base/Front, CutMaster
Overlay, Front Panel, CutMaster
Overlay, Control Panel, CutMaster
USA Label (1-3/4 X 3) 8-3216
Ground Tag 8-4243
2 1 Contactor, 4 Pole, 40 FLA 120 VAC 9-7507
3 1 Strain Relief - .325-.360 Dia. 8-5537
4 2 Fan, 115V, 50/60Hz, 95/115CFM w/.187 Tabs 8-3209
5 1 Cable, Work, #6 AWG w/Clamp
15' (4.6 m) Length 9-7540
20' (6.1 m) Length 9-8008
6 1 Assembly, Pot/Led PCB Replacement Kit (PC Board & Knob) 9-7014
7 1 Knob, Inner Concentric
Current Pot Shaft Diameter 1/8 Inch - Order Kit 9-7014
Current Pot Shaft Diameter 1/4 Inch - Knob Only 9-8007
8 1 On/Off Rocker Switch, DPST 8-3258
9 1 Switch, Rocker SPST (Run/Set) 9-1042
