Manual 0-2725 A-1 APPENDIX
APPENDIX 1: INPUT WIRING REQUIREMENTS
NOTES
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired installations
refer to local or national codes.
Cable conductor temperature used is 167° F (75° C).
An energy limiting fuse UL Class RK-1 (examples: BUSS LPS/LPN-RK or Gould-Shawmut AZK-A6K) should be
used to minimize damage to Plasma Cutting, Welding or power distribution equipment.
NEVER use replaceable element fuses like UL Class H, or "one-time" fuses like UL Class K5.
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps)
Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph
208 50/60 11.6 32.3 40 4
230 50/60 11.9 29.9 35 4
240 50/60 12 29 35 4
380 50/60 13.4 20.4 30 4
415 50/60 13.8 19.2 25 4
460 50/60 14.2 17.9 25 4
Line Voltages with Suggested Circuit Protection and Wire Sizes
