.....Direct menu access
The address must be entered while the M is displayed (within approximately 4 seconds). If the M is no
longer displayed, press MENU again followed by the 2-digit address.
Menu Type Display Menu Menu Type Display Menu
Primary Flow/Net Totalizer 00 Options Measurement Units 42
Flow/Velocity 01 Site Parameters 43
Flow/Positive Totalizer 02 RS232 Configuration 46
Flow/Negative Totalizer 03 Change System Password 47
Signal Strength/Low Signal 04 Change Scale Factor 48
Cutoff Password
Unit ID 49
Pipe Pipe OD 10
Pipe Wall Thickness 11 Calibration 50
Pipe ID 12 Zero Set 51
Pipe Material 13 Scale Factor 52
Pipe Sound Speed 14 Sound Speed 53
Pipe Inside Roughness 15 Compensation
Date and Time 54
Liner Liner Material 16
Liner Thickness 17 Current Loop 56
Liner Sound Speed 18 Current Loop Span 57
Liner Inside Roughness 19 Current Loop Calibration 58
Current Loop Test 59
Fluid Fluid Type 20
Fluid Sound Speed 21 Alarms 70
Fluid Viscosity 22 Program Alarms 71
View Alarms 72
Transducer Transducer Type 23
Transducer Mounting 24 Datalog Datalog Setup 80
Transducer Spacing 25 Datalog Interval 81
Flow Flow Units 30 Diagnostics Signal Strength/Margin 90
Max Flow Range 31 Delta Time/Fluid Sound 91
Min Flow Range 32 Speed
Damping 33 Reynolds #/Profile Factor 92
Low Flow Cutoff 34 Current Loop Output 93
Low Signal Cutoff 35 Software/Firmware Rev. 94
Level
Totalizer Totalizer Units 36
Totalizer Multiplier 37 Print Print Log Setup 96
Net Totalizer 38 Print Settings 97
Positive Totalizer 39 Print Diagnostic 98
Negative Totalizer 40 Print Current Screen 99
Totalizer Reset 41
TABLE 2: MENU ADDRESSES
