Table A-1
Steel, Stainless Steel, and PVC Pipe Standard Schedules
Inside Diameter (ID) and Outside Diameter (OD) in Inches
Nominal
Pipe
Size
OD
Sched.
5
Sched.
10
(light
wall)
Sched.
20
Sched.
30
Sched.
40
Sched.
60
Sched.
80
Sched.
100
Sched.
120
Sched.
140
Sched.
160
Std.
Wall
X STG
1 1.25 1.5 2 2.5
1.315 1.660 1.900 2.375 2.875
1.185 1.530 1.770 2.245 2.709
1.097 1.442 1.682 2.157 2.635
1.049 1.380 1.610 2.067 2.469
0.957 1.278 1.500 1.939 2.323
0.815 1.160 1.338 1.687 2.125
1.049 1.380 1.610 2.067 2.469
0.957 1.278 1.500 1.939 2.323
3 3.5 4 5 6
3.500 4.000 4.500 5.563 6.625
3.334 3.834 4.334 5.345 6.407
3.260 3.760 4.260 5.295 6.357
3.068 3.548 1.026 5.047 6.065
2.900 3.364 3.826 4.813 5.761
3.624 4.563 5.501
2.624 3.438 4.313 5.187
3.068 3.548 4.026 5.047 6.065
2.900 3.364 3.826 4.813 5.761
8 10 12 14 16
8.625 10.750 12.750 14.000 16.000
8.407 10.482 12.438 15.670
8.329 10.420 12.390 13.500 15.500
8.125 10.250 12.250 13.376 15.376
8.071 10.136 12.090 13.250 15.250
7.981 10.020 11.938 13.124 15.000
7.813 9.750 11.626 12.812 14.688
7.625 9.562 11.374 12.500 14.312
7.367 9.312 11.062 12.124 13.938
7.187 9.062 10.750 11.876 13.562
7.001 8.750 10.500 11.500 13.124
6.813 8.500 10.126 11.188 12.812
7.981 10.020 12.000 13.250 15.250
7.625 9.750 11.750 13.000 15.000
18 20 24 30 36
18.000 20.000 24.000 30.000 36.000
17.670 19.634 23.564 29.500
17.500 19.500 23.500 29.376 35.376
17.376 19.250 23.250 29.000 35.000
17.124 19.000 22.876 28.750 34.750
16.876 18.812 22.624 28.500 34.500
16.500 18.376 22.062
16.124 17.938 21.562
15.688 17.438 20.938
15.255 17.000 20.376
14.876 16.500 19.876 31.876
14.438 16.062 19.312 31.312
17.250 19.250 23.250 29.250 35.250
17.000 19.000 23.000 29.000 35.000
42 48
42.000 48.000
41.000
40.750
40.500 47.250
41.250 47.250
41.000 47.000
