4.Ifatoolforremovingconnectorsisincludedinthepackagewiththenewcard,usethetooltodisconnect
thecablesfromthecard.Ifnosuchtoolisincluded,disconnectthecablesbypickinguptheconnectors
withyourfingersandgentlyunpluggingthem.
5.Removethescrew1.ThewirelessWANcardpopsup.RemovetheWANcard2.
6.AlignthecontactedgeofthenewWANcardwiththecorrespondingsocket1.PivottheWANcarduntil
youcansnapitintoplace.SecuretheWANcardwiththescrew2.
Chapter6.Replacingdevices77
