TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 9 06/04/24 Thomson Technology
19
5. TSC 800 DISPLAY MENUS
The TSC 800 contains a Liquid Crystal Display (LCD) that is visible on the front faceplate. The LCD
has pre-programmed display menus which are automatically displayed in an auto-Scrolling mode or
they may be selected manually by pressing the ENTER or EXIT pushbuttons in succession until the
desired menu is displayed. The display menu types and order in which they are programmed are as
follows:
NOTE:
The following display menus are provided in TSC 800 Software
version 2.0 (or higher).
SYSTEM TIME
STATS MENU
ATS MODE MENU
PROGRAM MENU
SYSTEM STATUS TIMER COUNTDOWN
UTILITY SUPPLY MENU
GEN SUPPLY MENU
NOTE: ATS MODE MENU access may be inhibited. Refer to programming instruction
for further details.
5.1. SYSTEM TIME MENU
The system time menu is used to show current system time and week number. The TSC 800
controller uses its internal time clock to reference when an automatic exercising operation (if
pre-programmed) is to occur. To change the system time, refer to the “time clock adjustment”
section of this manual.
NOTE:
The following system Time menu is provided in TSC 800
Software version 2.0 (or higher).
