TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 9 06/04/24 Thomson Technology
20
LCD DISPLAY
System Time
Mon
1
12:24:31
Displays the day of the week (e.g. Monday)
Displays the week number (e.g. 1-4)
Displays the current time in hours (24-hour clock): hour: min: seconds
5.2. ATS MODE MENU
The ATS Mode Menu provides manually selectable operating modes which includes
On/Offload testing features (comparable features also available via external inputs utilizing an
optional FTS4 selector switch). The Internal and External ATS Mode inputs operate in a
parallel fashion; the Mode of Operation will be determined by the highest priority selected by
either format. The priority levels are as follows (highest to lowest priority):
1) Off (Controller out of Service, no control logic applied)
2) Onload Test
3) Offload Test
4) Auto
A utility power failure will over ride all but “Off”. In the event of a generator failure and the
utility supply is available and considered normal, the ATS will return to the utility supply except
when “Off” selected.
NOTE:
The following test menu is provided in TSC 800 Software
version 2.0 (or higher).
The ATS Mode sub-menus are organized as follows:
ATS Mode Menu No
Yes Auto (Automatic Operation & Programmed Test Mode)
Offload Test Continuous Test
Onload Test
Off (Controller Disabled) Timed Test: Selectable
15 - 240 Min.
Automatic Return to “Auto Mode”
To Next Page
