9. TSC 800 TYPICAL CONNECTION DIAGRAM
GEN ERAT OR CO NTR OL POW ER
115 or 230VAC
PRE-T RANS FER T O G ENERAT OR
RATED 3A, 250VAC RES. MAX.
DIM ENSIONS
FACEPLATE : 5.5" x 5.5" [140mm x 140mm]
PRINTED CIRCUIT BOARD: 6.30"W x 12.00"H [160mmW x 305mmH]
LAMP
TEST
AUTOMATIC TRANSFER C ONTROLLER
MODEL TSC 800
EX IT DE CREM ENT IN CREM ENT ENTER
TB2-15
TB3-4
TB 3-11
TB3-1
TB3-6
TB3-5
TB3-2
TB3-3
TB3-9
TB3-8
TB3-7
TB2-3
TB2-2
TB2-1
TB 3-10
TB2-4
TB2-5
TB2-6
ENG INE
ST ART
CON TACT
RAT E D 10A , 250VAC RES. M AX.
PRO GRAMMA BL E
OUT PUT
RAT E D 10A , 250VAC RES. M AX.
N
L
L
OFF
A
B
C
A
B
C
UTILITY SUPPLY SENSING
120-600VAC
50/60Hz
3 PHASE
GENERATOR SUPPLY
SENSING
120-600VAC
50/60Hz
3 PHASE
LOAD SENSING
120-600VAC
50/60Hz
1 or 3 PHASE
TB1-1
TB1-2
TB1-3
TB1-4
TB1-5
TB1-6
UT ILIT Y CO NT ROL POW ER
115 or 230VAC
LO AD ON UT ILITY SUPPL Y
TR ANSF ER T O U TILIT Y
RATED 10A, 250VAC RES. MAX.
UT ILITY NOR MAL
PROG RAMMA BL E OU TPUT
RATED 3A, 250VAC RES. MAX.
PRE-T RANS FER T O U TILITY
RATED 3A, 250VAC RES. MAX.
LO AD ON GEN ERA TOR SUPPL Y
TR ANSF ER TO GEN ER ATO R
RATED 10A, 250VAC RES. MAX.
GENE RAT OR NO RMAL
PROG RAMMA BL E OU TPUT
RATED 3A, 250VAC RES. MAX.
CONNECTION DIAG RAM
2 x 16 CHARACTER
DISPLAY
EXTERNAL
4 POSITION
TEST SW ITCH
(OPTIONAL)
1
1
2
2
1
2
CONTROL POW ER INPUT VOLTAGE MUST
MATCH TSC 800 MODEL TYPE
UTILITY AND GENERATOR SUPPLIES M UST
UTILIZE A SOLIDLY GROUNDED NEUTRAL
SYSTEM. REFER TO INSTRUCTION MANUAL FOR
ALTERNATE CONNECTIONS
V
REF
REVISED
04-12-15 11:00 AM
NOTE:
3 PHAS E STANDARD ATS CONNECTIONS
SHOW N ONLY.
SEE MANUAL FOR ALTERNATE CONNECTION DIAGRAMS
FULL FILENAME
DRAW ING1
SERVICE
ENTRANCE
TB2-16
ENGINE START
TB2-17
TEST
TB2-12
CLOSED
TRANSITION
SYSTEM GROUND
GRD
TB2-18
A
B
C
TB1-7
TB1-8
TB1-9
NOT E : P ro g r am m able
ou tpu t n o t av a ila ble
fo r c u stom e r use o n
Insu la ted Cas e AT S
TB2-13
TB2-14
