TSC 800 TRANSFER SWITCH CONTROLLER
PM 049 REV 9 06/04/24 Thomson Technology
42
NOTE:
If an invalid number is entered, programming access will be
limited to time clock adjustment only. To exit the programming
mode, press the EXIT pushbutton and hold for two seconds
until the display scrolls rapidly.
When the programming mode is accessed, the programming parameters will be
displayed in the same order as the Programming Data Sheet provided with the
transfer switch. To skip over parameters that do not require changes, push and hold
the ENTER pushbutton until the desired function is displayed. The EXIT pushbutton
may be used to scroll backwards through the programming parameter loop, but only
one keystroke at a time, maintaining it longer than 2 seconds will exit the program
menu.
To change a programmed parameter, use the INCREMENT or DECREMENT
pushbuttons to scroll through the available options or to adjust a value up or down to
the desired number. When the desired option or number is displayed, press the
ENTER pushbutton to accept the new value. Pressing the EXIT pushbutton after a
new value is applied will result in the new value being overwritten with the original
value.
NOTE:
If the programming mode is terminated before the last change
had been entered, the programming parameter will remain
unchanged.
To exit the programming mode, press the EXIT pushbutton and hold for two seconds
until the display scrolls rapidly.
7.2. EXERCISE TIMER
NOTE:
The following exercise timer feature is provided in TSC 800
Software version 2.0 (or higher).
The TSC 800 controller has a built-in programmable exercise timer, which allows up to a 4
week (28 day), exercise time period. The timer is fully programmable for, day of week, time of
day, duration of the test and type of test mode (i.e. On Load or Off Load). The exercise timer
utilizes the TSC 800’s internal time clock for referencing all timing functions. The time clock
