Week Number is programmable only if the System Time Clock
Rollover period is set longer than 7 days. Ensure Auto Test
Stop Day/Week/Timer occurs after the Auto Test Start
Day/Week/Timer setting (Generally of the same day/week)
otherwise the generator may operate for an extended period of
time.
7.2.6. AUTO TEST STOP HOUR
Select the hour of the day (e.g. 0-23 hour) that the generator set is to be stopped
following its exercise period.
7.2.7. AUTO TEST STOP MINUTE
Select the minute of the day (e.g. 0 to 59 minutes) that the generator set is to be
stopped following its exercise period.
7.2.8. AUTO TEST MODE
Select type of test mode desired. Three test modes are available as follows:
Auto: The exercise test mode is de-activated
Off Load: The generator set will be started during the exercise period but no
transfer will occur.
NOTE: The generator will transfer on load if the utility supply fails during the
test period.
On Load: The generator will be started and will transfer on load.
NOTE: During the On-Load exercise test mode, the transfer switch will
automatically re-transfer back to the utility supply if the generator set fails.
7.3. SYSTEM CONFIGURATION
The TSC 800 controller provides a flexible control system to allow specific operation for a wide
range of power distribution types. To program the system configuration, refer to the following
descriptions:
7.3.1. FIRMWARE VERSION
“Display Only” - The Controller’s current firmware version number and date of release.
