© 2013 Thorlabs GmbH
3 Operation
81
Line view (horizontal)
Opens the Line view window (row view)
Line view (vertical)
Opens the Line view window (column view)
Histogram
Opens the Histogram window
Zoom window
Opens the Zoom window
Pixel peek window
Opens the Pixel peek window
Waterfall window
Opens the Waterfall window
Log window
Opens the Log window
Image infos
Opens the Image infos window
3.4.2.5.4 uc480
The "uc480" menu contains functions for image capture and camera configuration.
Initialize
Open camera and show live image
Initialize and stop
Open camera
Standby
The camera changes to standby mode
Close
Close camera
Reset to defaults
Resets all values set in the demo program to the defaults
Start live video
Live video on/off
Snapshot
Snapshot from live video
Sync Trigger (Rising Edge)
Starts capture in freerun synchronization mode on the specified edge of the
trigger signal.
The freerun synchronization mode is currently not supported by DCx camera
models.
Sync Trigger (Falling Edge)
Single trigger
Triggered snapshot (software trigger)
Continuous trigger
Continuous triggered capture on/off
Trigger source hardware/software can be set in the corresponding property
page
Properties ...
Opens the camera properties dialog
Auto contrast
Activate automatic brightness control
Set new AES/AGC AOI
Define active area for automatic brightness control
Clear AES/AGC AOI
Clear active area defined for automatic brightness control
Auto whitebalance
Activate automatic white balance
Set new AWB AOI
Define active area for automatic white balance
Clear AWB AOI
Clear active area defined for automatic white balance
Sharpness measure AOI
Draw an AOI and measure sharpness within the AOI
Set new AOI
After calling "Set new AOI", you can select an area of interest with the
mouse
Clear AOI
Clears the area of interest (reset to full frame)
User allocated image
The memory is allocated not via the SDK function
is_SetAllocatedImageMem() , but by the application
Sound on transfer failed
Output an acoustic signal if a transmission error occurs
Error report
Errors are displayed in a dialog box
Clear counters
Reset the counters (see uc480 Viewer status bar)
