Page #19 background imageLoading...
Page #19 background image
14 DCx camera
© 2010 Thorlabs
2
General Information
2.1
At a glance
This manual describes the hardware operation of the DCx series USB 2.0 camera.
The DCx camera family uses CCD sensors using the global shutter method as well as CMOS
sensors with rolling shutter.
The resolution of the DCx cameras varies from 1024 x 768 pixels (XGA) to 1280 x 1024 pixels
(SXGA). Thanks to the rugged metal housing and the small constructional design, the cameras are
perfectly suited for use in industrial and medical applications.
DCx cameras are available as both monochrome and color cameras.The images are digitised in the
camera and transmitted to a PC via the standard USB2.0 interface. An additional frame grabber is
not necessary.The USB2.0 interface is now available in every current PC and notebook/laptop and
provides a band width of 480 Mbit. DCU cameras are fully Plug & Play. The camera is connected by
just a single cable. Image and control data and power supply from the PC is transmitted through this
cable. A separate power supply is not necessary.
A Software Development Kit (SDK) is provided with DCU cameras to allow their integration into own
programs under Windows 2000 and XP (32 bit), Windows Vista and Windows7 (32 and 64 bit) and
LINUX. All information about programming can be found in the Software Development Kit section
of this manual.
Please, read the file WhatsNew.txt, which is on the installation CD. Here you can find additional
information, which is possibly not contained in the printed edition of the manual.
We would like to wish you every success with the product.
2.2
Ordering Codes and Accessories
Ordering code Short description
DCC1545M CMOS Camera, 1280 x 1024 Resolution, B&W, USB 2.0, CS-mount
DCC1645C CMOS Camera, 1280 x 1024 Resolution, Color, USB 2.0, CS-mount
DCU223M CCD Camera, 1024 x 768 Resolution, B&W, USB 2.0, C-mount
DCU223C CCD Camera, 1024 x 768 Resolution, Color, USB 2.0, C-mount
DCU224M CCD Camera, 1280 x 1024 Resolution, B&W, USB 2.0, C-mount
DCU224C CCD Camera, 1280 x 1024 Resolution, Color, USB 2.0, C-mount
Accessories
CAB-DCU-T1 Trigger Cable for DCU22x Cameras (Trigger In/Out)
CAB-DCU-T2 Trigger Cable for DCU22x Cameras (Trigger In only)
MVL8L 8 mm, f/1.4, Lockable, Camera Imaging Lens*
MVL12L 12 mm, f/1.8, Lockable, Camera Imaging Lens*
MVL16L 16 mm, f/1.4, Lockable, Camera Imaging Lens*
MVL25 25 mm, f/1.6, Camera Imaging Lens*
MVL35L 35 mm, f/2.1, Lockable, Camera Imaging Lens*
MVL50L 50 mm, f/2.8, Lockable, Camera Imaging Lens*
MVL75L 75 mm, f/3.9, Lockable, Camera Imaging Lens*
*C-mount, adapter ring to CS-mount included with DCC1x45x Cameras
Please visit our homepage http://www.thorlabs.com for further information.
84
