275SDK (Software development Kit)
© 2010 Thorlabs
7.3.97
is_SetOptimalCameraTiming
USB 2.0
USB 2.0
Syntax
INT is_SetOptimalCameraTiming (HIDS hCam,
INT Mode, INT Timeout, INT* pMaxPxlClk,
double* pMaxFrameRate)
Description
Using is_SetOptimalCameraTiming(), you can determine the highest possible pixel clock
frequency for the current configuration. This function sets the pixel clock for which no transfer errors
will occur during the Timeout period. Moreover, it returns the highest frame rate available for this
pixel clock frequency. is_SetOptimalCameraTiming() can only be executed in free-run mode (
is_CaptureVideo() ). If the return value is ? IS_SUCCESS, no clock setting will be made.
The function should be executed in a separate thread and run in the background to allow for the
computational load caused by additional colour conversions, etc. Otherwise, it will not able to
return the optimum values.
Input Parameters
hCam
Camera handle
Mode
IS_BEST_PCLK_RUN_ONCE
The function makes one attempt to determine the optimum pixel
clock and returns immediately.
Timeout
[4000...20000]
Sets the period (in milliseconds) during which no transfer error
may occur. The adjustable range is between 4 and 20 seconds.
The higher the value you set for this parameter, the more stable
the determined pixel clock value will be. This, in turn, increases
the runtime of the function correspondingly.
pMaxPxlClk
Returns the maximum pixel clock frequency (in MHz).
pMaxFrameRate
Returns the maximum frame rate (in fps).
Return Values
IS_SUCCESS
Function executed successfully
IS_NO_SUCCESS
General error message
IS_AUTO_EXPOSURE_RUNNING
Automatic exposure is active.
IS_INVALID_PARAMETER
The Timeout input parameter is not correct.
IS_TRIGGER_ACTIVATED
The camera is operating in trigger mode.
124
