THORLABS DCU223 SERIES User Manual

272 DCx camera
© 2010 Thorlabs
hCam
Camera handle
x
0...xMax
Sets the horizontal position
0...xMax
| IS_SET_IMAGE_POS_X_ABS
Applies the absolute position to the memory as well.
IS_GET_IMAGE_POS_X
Returns the current x position.
IS_GET_IMAGE_POS_X_MIN
Returns the minimum value for the horizontal AOI position.
IS_GET_IMAGE_POS_X_MAX
Returns the maximum value for the horizontal AOI position.
IS_GET_IMAGE_POS_X_INC
Returns the increment for the horizontal AOI position.
IS_GET_IMAGE_POS_X_ABS
Returns the absolute horizontal position in the memory.
IS_GET_IMAGE_POS_Y
Returns the current Y position.
IS_GET_IMAGE_POS_Y_MIN
Returns the minimum value for the vertical AOI position.
IS_GET_IMAGE_POS_Y_MAX
Returns the maximum value for the vertical AOI position.
IS_GET_IMAGE_POS_Y_INC
Returns the increment for the vertical AOI position.
IS_GET_IMAGE_POS_Y_ABS
Returns the absolute vertical position in the memory.
y
0...yMax
Sets the vertical position
0...yMax
| IS_SET_IMAGE_POS_Y_ABS
Applies the absolute position to the memory as well.
0
When returning settings via parameter x (s. above)
Return Values
IS_SUCCESS
Function executed successfully
IS_NO_SUCCESS
General error message
IS_INVALID_PARAMETER
Parameters x or y are invalid (x, y < 0)
Current setting when used together with
IS_GET_IMAGE_POS parameters
IS_INVALID_MODE
Camera is in standby mode, function not allowed.
Related Functions
is_SetAOI()
219
