50 DCx camera
© 2010 Thorlabs
Auto
Automatic black level correction (Recommended). The camera tries internally always to retain
the black value to 0. In the default setting Auto should be activated. Depending upon model a
deactivation does not always guarantee a correct black level.
Red gain [0 ... 100]
Amplification of the red color values
Green gain [0 ... 100]
Amplification of the green color values
Blue gain [0 ... 100]
Amplification of the blue color values. The hardware RGB gain controllers are selectable only with
the color models.
Edge enhancement
Edges can be emphasized with Edge enhancement. In connection with the color sensors, this
function can be used to counteract edge softening caused by Bayer Mosaic conversion. Activating
the Edge enhancement function results in increased processing during image capture.
Gamma
Software gamma (1.6)
Gamma correction with the value 1.6. Dark image areas are raised. Software gamma should be
used only for visualization. For image processing Software gamma must be deactivated to get a
linear illustration.
Hardware gamma
Gamma correction by the hardware. Not available for DCU / DCC cameras.
