Page 24
MTN028837-D02
PM5020 Dual-Channel Benchtop Power and Energy Meter Chapter 4 Operating Instructions
2) Single Channel
2.1) Math View
When sensors of the same kind, two photo sensors, two thermal sensors or two pyroelectric sensors, are
connected, the Math View can be opened from within the Single Channel screen to view calculation res-
ults. To activate the display of calculation results, enter a formula in the Setting Menu under "Math".
3) Analog Needle and Thermal Position Sensor Display
Note
To have the measurement screens Logging, Statistics and Scope appear and accessible in the top bullets,
select at least one channel in the Setting Menu.
4) Logging
This interface allows to record measurement with one or two channels.
