Page 36
MTN028837-D02
PM5020 Dual-Channel Benchtop Power and Energy Meter Chapter 4 Operating Instructions
Math: Perform two independent calculations between both channels or on just one of both channels and
one constant for each channel in the PM5020 power meter interface.
The drop down lists are interactively filled with each previously set action.
The compared measurement values between two channels can also be displayed in percent.
Please find the possible functions in the table below:
(CH x <operation 1> Constant 1) <operation 3> (CH y <operation 2> Constant 2) = [Units]
The number has, depending on the operation, the same unit as CHx or no unit.
* W/cm² is treated like W
