© 2007-2012 Thorlabs GmbH
98 WFS Series
In case the distance to the point source is measured too short or too far the following
error occurs.
Change the setup accordingly and repeat the calibration.
After successful calibration you are asked if the reference data should be saved to a
file.
Click 'Yes' to store this user calibration to a predefined file within your application
directory to have it available in following Wavefront Sensor sessions. Otherwise, if
you click 'No' the calibration remains in memory and active but is lost as soon as the
program is terminated. Also when the sensor resolution (see Camera Settings ) or
the MLA (see Wavefront Setup ) is changed and the appropriate reference file is
loaded, the current reference in memory gets lost.
In order to be distinctively the user reference file name is automatically composed
of the
WFS serial number
MLA name
Camera resolution index
for instance WFS_M00224955_MLA150M-5C_2.ref. The file itself is stored into the
application directory.
6
7
79
