© 2007-2012 Thorlabs GmbH
100 WFS Series
4.2.7
Save Measurement Data
The measured wavefront data can be saved to a text file. The preferred file extension
is .csv (comma separated values). This file type can be loaded directly into Microsoft
Excel®.
You may define some file preferences before storing the measurement data file.
Choose the menu item File Measurement File Preferences.
The separation character between the parameter name and the appropriate value
can be set to four different characters:
'Comma' is selected by default.
The decimal character can be set to a decimal comma or point in order to achieve
the desired output format.
'Point' is selected by default.
If the option 'Omit Header Data' is enabled the entire header including the listing of
single wavefront and Zernike fit results is omitted and only the wavefront data array is
saved. This wavefront data array is surrounded by x- and y-scale information,
whereas the first column indicates the x coordinates and the last row indicates the x
coordinates of the wavefront array.
Choose menu item File Save Measurement Data or just press Ctrl + S to save
the wavefront data file to disk using the defined preferences. For the file content see
this printout of a sample file:
Thorlabs Shack-Hartmann Wavefront Sensor
Model , WFS150C
Serial Number , M00224955
