16
16
NV10P - Manual - 01 - 2015
TECHNICAL DATA
3.6 GENERAL SETTINGS FOR INDUCTIVE VTs VERSIONS
Relay nominal frequency (f
n
) 50, 60 Hz
Relay nominal voltage (U
n
) 50...130 V
[1]
(step 1 V)
200...520 V
[2]
(step 1 V)
Relay residual nominal voltage (U
En
) 50...130 V (step 1 V)
Calculated relay residual nominal voltage (U
ECn
) U
ECn
= √3U
n
Line VT primary nominal voltage (U
np
) 50 V...500 kV
50...499 V (step 1 V)
500...4990 V (step 10 V)
5000...49900 V (step 100 V)
50000...500000 V (step 1000 V)
Residual primary nominal voltage (phase-to-phase) ∙√3 (U
Enp
) 50 V...500 kV
50...499 V (step 1 V)
500...4990 V (step 10 V)
5000...49900 V (step 100 V)
50000...500000 V (step 1000 V)
3.6.1 GENERAL SETTINGS FOR SENSOR VERSIONS
Relay nominal frequency (f
n
) 50, 60 Hz
Relay nominal voltage (U
n
) 50...130 V
[2]
(step 1 V)
Relay residual nominal voltage (E
n
) E
n
= U
n
/√3
Calculated relay residual nominal voltage (U
ECn
) U
ECn
= √3U
n
= 3 E
n
Line VT primary nominal voltage (U
np
) 50 V...500 kV
50...499 V (step 1 V)
500...4990 V (step 10 V)
5000...49900 V (step 100 V)
50000...500000 V (step 1000 V)
3.7 PROTECTIVE FUNCTIONS
Thermal protection with Pt100 probes - 26
[3]
ThAL1...8 Alarm:
Alarm threshold 26 PT1...PT8 (Th
AL1...8
) 0...200 °C
Operating time ThAL1...8 (tTh
AL1...8
) 0....100 s
Th>1...8 Trip:
Trip threshold 26 PT1...PT8 (Th>
1...8
) 0...200 °C
Operating time ThAL1...8 (tTh>
1...8
) 0....100 s
Undervoltage - 27 for inductive VTs versions
Common confi guration:
27 Operating logic (Logic27) AND/OR
U< Element
U< Curve type (U<
Curve
) DEFINITE/INVERSE
[4]
Defi nite time
27 First threshold defi nite time (
U
<
def
) 0.05...1.10 U
n
(step 0.01 U
n
)
U<
def
Operating time (t
U
<
def
) 0.07...100.0 s
0.07...9.99 s (step 0.01 s)
10.0...100.0 s (step 0.1 s)
Inverse time
27 First threshold inverse time (
U
<
inv
) 0.05...1.10 U
n
(step 0.01 U
n
)
U<
inv
Operating time (t
U
<
inv
) 0.10...100.0 s
0.10...9.99 s (step 0.01 s)
10.0...100.0 s (step 0.1 s)
Element U<<
Defi nite time
27 Second threshold defi nite time (
U
<<
def
) 0.05...1.10 U
n
(step 0.01 U
n
)
U<<
def
Operating time (t
U
<<
def
) 0.07...100.0 s
0.07...9.99 s (step 0.01 s)
10.0...100.0 s (step 0.1 s)
Note 1 The setting ranges of the relay nominal voltage U
n
are dependent on the version (to be selected on purchase), with reference voltages U
R
100 V
or 400 V.
Note 2 When the rated voltage of the electricity network divided by √ 3 corresponds to the value of rated primary voltage of the sensors (20000 / √ 3),
then the nominal voltage of the relay must be adjusted to Un = 100 V (default setting).
Note 3 The 26 element is available when the MPT module is connect on Thybus and enabled
Note 4 The mathematical formula for INVERSE curve is: t= (0.75 ∙ t
U
<
inv
) / [1 - (U/U<
inv
)]
t = operating time (in seconds)
t
U
<
inv
= operating time setting (in seconds)
U = input voltage
U<
inv
= threshold setting
