CHARACTERISTICS
Breaker failure (BF)
All undervoltage elements can produce the Breaker Failure output if the U< BF and U<< BF pa-
rameters are set to ON. The parameters are available inside the Set \ Profi le A(or B) \ Undervoltage
- 27 \ U< Element (U<< Element) \ Setpoints menus.
[1]
All the named parameters can be set separately for Profi le A and Profi le B (Set \ Profi le A(or B) \
Undervoltage - 27 \ U< Element (U<< Element) \ Setpoints menus).
For every of the two thresholds the logic block can be set.
Logical block (Block1)
If the U<BLK1 and/or U<<BLK1 enabling parameters are set to ON and a binary input is designed
for logical block (Block1), the protection is blocked off whenever the given input is active.
The trip timer is held in reset condition, so the operate time counting starts when the input block goes
down.
[2]
The enabling parameters are available inside the Set \ Profi le A(or B) \ Undervoltage - 27 \
U< Element (U<< Element) \ Setpoints menus, while the Block1 function must be assigned to the
selected binary input inside the Set \ Inputs \ Binary input IN1(x) menus (IN1 or INx matching).
Note 1 The common settings concerning the Breaker failure protection are adjustable inside the Breaker Failure - BF menu.
Note 2 The exhaustive treatment of the logical block (Block 1) function may be found in the “Logic Block” paragraph inside CONTROL AND MONITOR-
ING section.
Logic diagram concerning the second threshold (U<<) of the undervoltage element - 27
Fun-F27_S2.ai
RESET
t
U<<
0T
TRIPPING MATRIX
(LED+RELAYS)
t
U<<def
Start U<<
Start U<<
Trip U<<
Trip U<<
Trip U<<
BF Enable (ONEnable)
towards BF logic
&
U<< BF
&
&
&
&
Enable (ONEnable)
Block1 input (ONBlock)
Block1
Block1
&
(ON
Inhibit
)
U< Inhibition
U<disbyU<<
Binary input INx
T0
Logic
INx
t
ON
INx
t
ON
INx
t
OFF
T0
n.o.
n.c.
INx
t
OFF
U<<ST-K
U<<TR-K
U<<ST-L
U<<TR-L
U<<BF
BLK1U<
U<<BLK1
Logic27
≥1
&
U
L1
U
L2
U
L3
&
State
U
U<
def
U<<
def
Enable (ONEnable)
MMI
Disable 27 function by operator
1
(1DDI closed)
DDI state
(1upstream)
U<<disbyCB_OPEN
