Description Parameter Unit Setting range
VIN30-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN30-Function (B)
none
VIN30-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
VIN31-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN31-Function (B)
none
VIN31-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
VIN32-Function (A)
Reset LEDs | Set profi le | Fault trigger | Block1
| TCS1 | TCS2 | Trip ProtExt | Reset counters |
Reset CB Monitor | 52a | 52b | Open CB | Close
CB | Remote trip | 74VT ext. | f<-f> Control |
UE>> | 27V1 | 59V2 | U<
VIN32-Function (B)
none
VIN32-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Comtrade
Enable
OFF | ON
Enable Compression
OFF | ON
Remove fi les if Enabled=OFF
OFF | ON
Oscillography
Readings
State
Initialization | Upload from serial fl ash | Reset
| Wait | Store to serial fl ash | Start recording |
Acquire | Trigger | Stopped | Fail | Off
Serial fl ash state
OFF | Upload from serial fl ash | Store to serial
fl ash | Reset serial fl ash
Serial fl ash overrun
OFF | ON
Records
0 ... 0 step = 0
Buffer storage
% 0 ... 0 step = 0
Trigger Setup
Pre-trigger time
s 0.05 ... 1.00 step = 0.01
Post-trigger time
s 0.05 ... 60.00 step = 0.05
Element pickup trigger
ON | OFF
Trigger from outputs
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Binary input trigger
ON | OFF
Trigger from inputs IN1-IN32
IN1 | IN2 | IN3 | IN4 | IN5 | IN6 | IN7 | IN8 | IN9
| IN10 | IN11 | IN12 | IN13 | IN14 | IN15 | IN16
| IN17 | IN18 | IN19 | IN20 | IN21 | IN22 | IN23
| IN24 | IN25 | IN26 | IN27 | IN28 | IN29 | IN30
| IN31 | IN32
Trigger from inputs IN33-IN42
IN33 | IN34 | IN35 | IN36 | IN37 | IN38 | IN39 |
IN40 | IN41 | IN42
80% Buffer alarm
OFF | ON
Set sample channels
uL1
On | Off
uL2
On | Off
uL3
On | Off
uE
On | Off
Set analog channels
