SAWMILL ASSEMBLY
Blade Height Scale Installation
3
3-30 15doc110819 SAWMILL ASSEMBLY
3.11 Blade Height Scale Installation
1. Bolt the scale guide blocks to the scale mount bracket. Lower the saw head all the way down,
insert the scale into the slot in the bracket (from the bottom) and bolt the scale to the saw head.
See Figure 3-20.
FIG. 3-25
