OPERATION
4
4-15 doc110819 OPERATION
See Figure 4-12.
6. Move the saw head in the cutting direction so the back end of the tool is over the bed rail. Measure
the distance between the tool and the bed rail.
7. This measurement should equal the other two measurements taken. If it is not the same, adjust the
blade guide using the screws shown in the figure above.
8. Move the tool close to the other blade guide and repeat the adjustment procedure described above.
NOTE: If any adjustments to blade guide tilt were made, make sure the blade deflection is correct
(3 mm).
NOTE: After adjusting the blade guides, start the blade drive for a moment. Then stop the blade and
recheck if the blade guides are properly positioned.
FIG. 4-12
Poluzować nakrętki i obrócić odpowiednio wkręty
by wyregulować ustawienie rolki w płaszczyźnie pionowej
Loosen jam nuts and turn screws to adjust roller in
vertical plane
