OPERATION Loading, Turning and Clamping Logs
OPERATION doc110819 4-24
4
To Level a Log:
Shim one end of the log (e.g. using an optional leveling wedge) until the heart of the log measures
the same distance from the bed at both ends of the log.
See Figure 4-19.
FIG. 4-19
Leveling
Wedge
