Model: CD-36D 9. Option
- 39 -
9. Option
(1) Conductivity modifying column, Model: CLZ-2
(option)
200
9751.5 51.5
2-M8
40
20
(20)
35
150
60
Lid
NaCl filled in the
container
Sample Level
Sample Inlet
Sample Inlet
(Rc1/2)
Sample Outlet
(Rc1/2)
Flow Cell
Model: CLZ-1
Conductivity modifying column, Model: CLZ-2
In order to achieve stable measurement when the electrical conductivity of a sample is in the
neighborhood of 8 mS/m or less, a conductivity modifying column (Model: CLZ-2) is provided to be
combined as option.
(a) Setting
( i ) Set the column on a pole of 50A pipe (OD φ60.5) with the saddle attached to the column, and
combine with the flow cell, Model: CLZ-1.
(ii) The final end of the sample outlet line should be sloped down and opened to the air.
【IMPORTANT】 • E Make sure to install a pressure reducer and a flow regulating valve
before the sample inlet in the sample supply line.
