16
7.5. Unit ID Number Setting and Confirmation
Note that the Unit ID number setting must be performed when controlling the unit from a PC. Since the ID
number is not preset when the unit is supplied from the factory, be sure to set it after you purchase the unit.
7.5.1. Unit ID Number setting
If the "Id" indication flashes on the Memory/Unit ID Number display following the unit's
initialization or I/O configuration setting, set the Unit ID number.
[Single unit]
Set the unit for Unit ID No. 1.
Step 1. Press the Unit ID Number display key.
The indication of "1" will flash on the Memory/Unit ID Number display.
Step 2. Release the ID number key.
The setting is completed. (Note that the display continues to flash.)
7.4.3. Default signal flow
Signal flow is factory-preset as follows depending on the input/output configuration:
Note: For signal flow changes, refer to the software instruction manual.
11
2
3
24
5
6
11
2
23
4
35
46
11
22
33
44
55
66
11
2
3
25
4
6
7
8
11
2
23
35
4
6
47
8
11
2
3
5
4
26
7
8
9
10
Input Output Input Output Input Output
2-IN/6-OUT 2-IN/8-OUT 2-IN/10-OUT
Input OutputInput OutputInput Output
6-IN/6-OUT4-IN/8-OUT4-IN/6-OUT
To Next Page
