42
Power Source
Power Consumption
Frequency Response
Sampling Frequency
Dynamic Range
Total Harmonic Distortion
Input
Output
100 – 240 V AC, 50/60 Hz
30 W
20 – 20,000 Hz (±1 dB)
48 kHz
110 dB (IHF-A weighted)
Less than 0.05%, 1 kHz, +4 dB* input/output (20 – 20,000 Hz BPF)
A/D Converter 24 bits
D/A Converter 24 bits
Level Control +12 to – ∞ dB (phase can be reversed.)
Equalizer/Filter
Signal Processing
Compressor
Noise Gate
Delay
Graphic equalizer: 1/3 octave band, 31 center frequencies (10 points adjustable),
±12 dB, Q:0.267 – 69.249, each band independently variable
Parametric equalizer: Frequency continuously variable type (20 – 20,000 Hz), 10 bands,
±12 dB, Q:0.267 – 69.249
Filtering:
High-pass filter 20 – 20,000 Hz, 12 dB/oct, 6 dB/oct
Low-pass filter 20 – 20,000 Hz, 12 dB/oct, 6 dB/oct
Notch filter 20 – 20,000 Hz, Q:8.561 – 69.249
Parametric filter 20 – 20,000 Hz, ±12 dB, Q:0.267 – 69.249
All-pass filter 20 – 20,000 Hz, Q:0.267 – 69.249
High frequency boost/cut 6 – 20 kHz, ±12 dB
Low frequency boost/cut 20 – 500 Hz, ±12 dB
Horn equalizer 20 kHz, 0 to +18 dB
Threshold: –16 to +24 dB*
Ratio: 1:1 – ∞ :1
Attack time: 0.02 – 100 ms
Release time: 10 ms – 5 s
Threshold: – ∞ to –26 dB*
Attack time: 0.1 – 100 ms
Release time: 20 ms – 5 s
Delay time: 0 – 682 ms
2 channels (expandable to up to 6 channels), +4 dB* (Max. +24 dB*),
10 kΩ, electronically-balanced, terminal block type connector (4 poles)
6 channels (expandable to up to 10 channels), +4 dB* (Max. +24 dB*),
adaptable load of over 600 Ω, electronically-balanced,
terminal block type connector (3 poles)
Matrix
2 x 6 (Expanded I/O configuration: 2 x 8, 2 x 10, 4 x 6, 4 x 8 , 6 x 6)
Level control: 0 to – ∞ dB (phase can be reversed.)
Channel Divider 2-way, 3-way, 4-way
Crossover frequency: 20 – 20,000 Hz (overlap mode)
Slope: 6 dB/oct, 12 dB/oct, 18 dB/oct, 24 dB/oct
Level: +12 dB to – ∞ dB (phase can be reversed.)
Delay: 0 – 682 ms
Muting Output muting
Memory
Auxiliary Function
Control
16 pattern memories
System Lock function
Control software: PC software (Windows 95/98/NT compatible)
Control system:
RS-232C D-sub connector (9 pins)
RS-485 Terminal block type 3-pole connector, Max. 30 units can be controlled.
Remote Control Module DQ-C01 (optional): Pattern memory selection, output volume
adjustment, external output muting control
10. SPECIFICATIONS
Panel Memory Recall key: 16 memories
Unit ID Number Display key: 30 units
Input level indicator: 6 channels, dual-color LED
Output level indicator: 10 channels, dual-color LED
Memory/Unit ID Number display: Double-digit, 7-segment LED
Master indicator: Green LED
